CNC Wood Engraving Machine

CNC Wood Engraving Machine

The Wood Engraving Machine from Competence Techno Engineers Pvt Ltd is designed for precise and detailed engraving on wood surfaces. Built with industrial-grade components and advanced motion control, this machine delivers high-speed performance and fine craftsmanship across a wide range of wood engraving applications.

Whether you're producing custom furniture, artistic panels, nameplates, or 3D wooden art, our machine offers consistent output, ease of use, and superior accuracy—making it one of the most reliable choices for anyone looking for a professional wood engraving machine.

Manufacturer: Competence Techno Engineers Pvt. Ltd.

Technical Specifications (customizable)

Specification

Details

  • Working Area (X/Y/Z)
  • 1300×2500×300 mm / Custom Sizes Available
  • Spindle Power
  • 3.2 / 5.5 / 6 kW (Air or Water Cooled)
  • Spindle Speed
  • 18000 – 24000 RPM
  • Drive System
  • Planetary Gearbox / Belt Drive
  • Motor Type
  • Stepper / Easy Servo / Servo
  • Transmission
  • X/Y – Helical Rack; Z – Ball Screw
  • Guide Rail
  • 25 / 35 mm LM Guide
  • Controller
  • DSP WEIHONG NK105 / Equivalent
  • Software Format
  • G-Code Compatible
  • Power Supply
  • 1PH 240V or 3PH 415V, 50Hz
  • Engraving Accuracy
  • ±0.05 mm
  • Key Features

    High-speed spindle ideal for intricate wood designs

    Durable MS steel body structure for vibration-free operation

    Smooth motion system with ball screw and helical rack drive

    G-code compatibility for complex and custom engraving patterns

    DSP or PC-based CNC controller for intuitive control

    Optional rotary axis for cylindrical wood engraving

    Excellent for 2D, 3D, and relief carving applications

    Applications

    Wooden nameplates and signage

    3D wood carving and sculpting

    Furniture design and embellishment

    Wood inlay and decorative patterns

    Artisan and architectural woodwork

    Trust Competence Techno Engineers Pvt Ltd for precision-driven wood engraving machines that deliver lasting performance. Contact us today for pricing, demos, and customization options.
