CNC Pattern Making Machine

CNC Pattern Making Machine

The CNC Pattern Making Machine is engineered for high-precision, high-speed production of wooden and metal patterns used in foundries, mold making, and prototyping. Built for durability and fine detailing, this machine is ideal for complex 2D and 3D shapes.

Whether you're working on pattern cutting or need a custom-built pattern cutting machine , our advanced solution offers consistent accuracy, repeatability, and superior surface finish.

Manufacturer: Competence Techno Engineers Pvt. Ltd.

Technical Specifications

Specification

Details

  • Working Area
  • X=1250/1830 mm
    Y=2500/3050/3650 mm
    Z=200 mm
  • Transmission
  • X=Helical Rack
    Y=Helical Rack
    Z= Ball Screw
  • Axis Motor
  • Stepper / Easy / Servo / Servo
  • Drive System
  • Belt Pully / Planetary Gear box
  • Linear Guide Rail
  • 25 mm LM Guide
  • Spindle Type
  • 3.5/4.5/6 kw (Air cooled)
    3.2/5.5/7.5 kw (water cooled)
  • Spindle RPM
  • 18000 to 24000
  • Max Travel Speed
  • 30000 mm/min
  • Machine Accuracy
  • 100 micron
  • CNC Controllers
  • DSP
  • Working Command
  • G-CODE
  • Lubrication
  • Auto / Manual

    • Key Features

    Optimized for foundry pattern and mold production

    Supports complex 2D/3D pattern cutting and shaping

    Strong MS steel frame for vibration-free operation

    Precision linear guides and ball screws for smooth movement

    High-speed air/water-cooled spindle options

    DSP or PC-based controller with G-code compatibility

    Easy integration with CAD/CAM software

    Applications

    Wooden and aluminum foundry pattern production

    Mold and core box development

    Automotive die and tooling

    Aerospace and prototyping molds

    Furniture and 3D design pattern making

    Competence Techno Engineers Pvt Ltd offers reliable, high-precision CNC pattern cutting machines tailored for foundry and industrial needs. Contact us today for detailed specs, pricing, and customization options.
