CNC Horizontal Milling Machine

The CNC Horizontal Milling Machine from Competence Techno Engineers Pvt Ltd is designed for high-precision machining of large and complex components. Engineered for heavy-duty performance, this machine is ideal for applications requiring stability, accuracy, and productivity in metal processing.

Whether you need efficient face milling, slot cutting, or contouring, this horizontal CNC milling machine ensures faster cycle times and superior surface finish—making it perfect for toolrooms, automotive, aerospace, and heavy engineering industries.

Manufacturer: Competence Techno Engineers Pvt. Ltd.

Technical Specifications

Feature

Specification

  • Working Area
  • X=1000/1500 mm
    Y=2000/3000 mm
    Z=300 mm
  • teansmission
  • X = Helical Rack / Ball Screw
    Y=Helical Rack / Ball Screw
    Z=Ball Screw
  • Axis Motor
  • Servo
  • Drive System
  • Planetary Gear box
  • Linear Guide Rail
  • 45/55 mm LM Guide
  • Spindle Type
  • BT 40/50 CTS
  • Spindle RPM
  • 6000 rpm
  • Spindle Motor
  • 7.5/9/11 KW Servo motor
  • Machine Accuracy
  • 50 To 80 micron
  • CNC Controller
  • PlC-HMI
  • Working Command
  • G-CODE
  • Lubrication
  • Auto operated pump

    • Key Features

    Rigid MS steel structure for vibration-free machining

    High-speed spindle with BT40/BT50 taper options

    CNC-controlled horizontal layout for better chip removal and efficiency

    Servo-driven axis movement for accurate multi-axis control

    Supports G-code programming for automation

    Heavy load-bearing table for larger workpieces

    Ideal for high-volume batch production and precision milling

    Applications

    Die and mold machining

    Gearbox and engine block milling

    Toolroom operations

    Aerospace component shaping

    Structural and heavy equipment part manufacturing

    Competence Techno Engineers Pvt Ltd provides robust and precision-engineered horizontal milling machines tailored to your production goals. Contact us today for specifications, pricing, and customized solutions.
