CNC Face Milling Machine

Home / CNC Milling Machine /

CNC Face Milling Machine

CNC Face Milling Machine

Competence Techno Engineers Pvt Ltd proudly offers a high-performance CNC Face Milling Machine designed for accurate and efficient surface finishing of metal components. Built for industrial reliability and RDSO-grade precision, this machine is ideal for flat surface preparation of railway components, base plates, machine beds, and other large fabricated structures.

Engineered for robust face milling operations, it accommodates a wide range of face milling cutters and ensures consistent, high-speed surface machining.

Manufacturer: Competence Techno Engineers Pvt. Ltd.

Technical Specifications

Feature

Specification

  • Working Area
  • X=1000/1500 mm
    Y=2000/3000 mm
    Z=300 mm
  • teansmission
  • X = Helical Rack / Ball Screw
    Y=Helical Rack / Ball Screw
    Z=Ball Screw
  • Axis Motor
  • Servo
  • Drive System
  • Planetary Gear box
  • Linear Guide Rail
  • 45/55 mm LM Guide
  • Spindle Type
  • BT 40/50 CTS
  • Spindle RPM
  • 6000 rpm
  • Spindle Motor
  • 7.5/9/11 KW Servo motor
  • Machine Accuracy
  • 50 To 80 micron
  • CNC Controller
  • PlC-HMI
  • Working Command
  • G-CODE
  • Lubrication
  • Auto operated pump

    • Key Features

    Rigid MS fabricated structure minimizes vibration

    Suitable for heavy-duty face milling and surface machining

    Compatible with a wide range of face milling cutter sizes

    Precise servo control on all axes

    Smooth surface finish ideal for RDSO-approved parts

    Customizable working area and milling depth

    Applications

    Flat surface milling of large metal plates

    Face milling of base plates, frames, and machine beds

    Preparation of weldable or machineable surfaces

    RDSO face milling machine applications for railway components

    As a trusted face milling machine manufacturer, Competence Techno Engineers Pvt Ltd delivers robust, reliable CNC solutions built for industrial performance and long-term precision.
